G1/4 Rear Connection Plastic Glycerine Pressure Gauge -1 to 0.6 bar 63mm WIKA
Glycerine-filled panel-mount compound gauge, -1 to 0.6 bar (≈-15 to 8.7 psi) with 0.05 bar scale divisions. Accuracy class 2.5: max. error ±0.04 bar. 63 mm plastic case, G 1/4 rear centre connection, dual bar/psi scale, IP65. Copper-alloy measuring element. Mounting bracket included.
- Regular price
- $44.35 USD
We sell only to registered businesses
Description
Glycerine-filled compound gauge for panel mounting, -1 to 0.6 bar (≈-15 to 8.7 psi) with 0.05 bar scale divisions. Accuracy class 2.5 means ±2.5% of the span, so the max. error is ±0.04 bar across the dial. The glycerine fill dampens the pointer, so the dial stays readable under vibration and pressure pulsation. Copper-alloy measuring element. For aggressive media, choose a gauge with stainless steel wetted parts. G 1/4 male thread at the rear. 63 mm plastic case, IP65, dual scale in bar and psi. Galvanised steel mounting bracket included. -20 to 60 °C.
Pros:
- -1 to 0.6 bar range, ±0.04 bar max. error (class 2.5)
- Glycerine fill for vibration and pulsation
- 63 mm plastic case, IP65
- Dual scale in bar and psi
- G 1/4 rear connection, mounting bracket included
Cons:
- Copper-alloy measuring element, not for aggressive media
- Not for use above 60 °C or below -20 °C
Series:
Glycerine-filled panel-mount pressure gauges with a 63 mm plastic case and IP65 protection. Accuracy class 2.5, copper-alloy measuring element, G 1/4 rear connection, and a galvanised steel mounting bracket. Dual scale in bar and psi. -20 to 60 °C. Ranges in this series: -1 to 0.6 bar and 0 to 1 bar.
